Die Casting Heat Treatment and T5/T6 Limits

Conventional high-pressure die castings contain entrapped gas. A full solution treatment at high temperature can expand that gas and cause surface blistering or internal defects.

That is why most die casting specifications avoid a full T6 treatment, even when the alloy family is nominally heat-treatable. The risk is a process limitation, not only a material one.

• Entrapped gas expands at high temperature
• Blistering is a common failure mode
• Full T6 is usually avoided
• Material and process both matter

A T5 treatment uses the residual heat from casting followed by controlled aging. It can improve some mechanical properties without the high-temperature solution step.

The achievable gain depends on the alloy, the part geometry and the process. The requirement should be confirmed with test data rather than assumed from a handbook value.

• T5 avoids the solution treatment
• Aging can improve some properties
• Gains depend on alloy and process
• Confirm with sample testing

Any thermal treatment can change dimensions. Parts with tight tolerances, sealing faces or flatness requirements should be evaluated for distortion before the treatment is specified.

If heat treatment is essential, the process route, fixturing and inspection plan must be agreed early, and the tool should be designed with the expected dimensional change in mind.

• Thermal treatment can move dimensions
• Flatness and sealing faces are at risk
• Plan fixturing and inspection
• Design the tool for the process route

Where higher strength is required, options include changing the alloy, increasing section thickness, adding ribs, using inserts, or moving the part to a different process such as gravity or low-pressure casting.

The right answer comes from the functional requirement, not from a default heat treatment specification. A DFM review should compare the options against cost and schedule.

• Consider alloy and geometry changes
• Inserts can carry local loads
• A different casting process may fit
• Compare options in DFM review
